Size and FitGeneralElectronicComponents

Content 1

Specifications
[A] Headlight height	86cm/33.8inch
[B] Handlebar minimum height	136cm/49.6inch
[C] Handlebar maximum height	132cm/60inch
[D] Frame minimum height	22.5mm/8.9inch
[E] Seat minimum height	67cm/24.6inch
[F] Seat maximum height	88cm/34.6inch
[G]Shelf length	40cm/15.7inch
[H]Shelf height	65cm/25.6inch
[I]Wheelbase Length	106cm/41.7inch
[J]Total Length	165cm/65inch

Content 2

Range

Accelerator: 150km/93miles
Assist: 200km/124miles

Speed

Default: 25kmh/15.5mph
Release: 50kmh/31mph

Pedal Assist

5 levels

Suspension

Front Spring Fork & Rear Suspension

Transmission

7 Speeds

Tires

Kenda 20'*4.0'

Folding parts

Rear Footrest

Bike Weight

36kg / 79lbs

Weight Capacity

180kg / 396lbs

Rider Height

165-200CM
64 - 78.7inc

Content 3

Motor

750w, 48V Brushless Rear Hub Motor

Maximum Torque

65 N.M

Battery

Lithium-ion 48V, 35Ah

Charger

54.6V 4AH Charger, 7-9 Hours Charging

Display

LCD Smart Easy Read Display, Colorful Screen

Content 4

Frame

Aluminum alloy

Handlebars

Aluminum 22.2mm, 700mm

Fork

Spring Suspension

Brakes

Hydraulic Disc Brakes

Horn / Bell

Horn

Wheels

Aluminum 36h Integrate Front & Rear

Headlight

LED Light

TailLight

Brake Light

Chain Ring

130-link 1/2 X 3/32

Pedals

Platform Pedals

Seat

Foldable and Swappable Wide Leather Seat

Emoko C94 Cargo Food Delivery ebike 150-200KM Long Range 48V 20*4 Inch Fat Tire Electric Bicycle
